Overall Width

Overall Height - Closed

Overall Height - Open

Overall Depth

Grapple Opening

Depth of Bucket

Tines

Bucket
Thickness

Bottom Plate

Grapple Arms

Cylinders

Hydraulic Couplers

Hydraulic Hoses

PSI Max

Pivot Points

Main Pin

Rear Cylinder Pin

Front Cylinder Pin

Weight

45", 45", 58¼", 71½"

28-3/4"

42-1/2"

39"

34"

26"

1-1/4" T-1 Steel - Replaceable

3/4"&1/2" Grade 50 Frame Work
Laser Cut

1/2" Grade 50

1/" Grade 50 - Laser Cut

3" Bore

Flat Face

1/2"

3,000 PSI

Grease Zerks

2" x 20"

1" x 6"

1" x 5.5"

45" = 685lbs, 45" 4 Tine = 798lbs
58" = 1389lbs, 72" = 1525lbs
